1290/1390 CO2 Laser Cutting Engraving Machine
Product Presentation
Machine Description
1290/1390 CO2 Laser Cutting Engraving Machine is a small portable modell machine for non-metal engraving and cutting.
Applicable for most materials as follows:
Cutting: Acrylic, Corian, MDF, Cork, Foam, Leather, Melamine, Plastics, Wood
Engraving: Cardboard, Fabric, Paper, Rubber
Machine Details
Integrated Vertical Industrial Control System
◆ Ergonomic Workstation & Path Optimization: Features an elevated vertical industrial PC screen with keyboard shelf to eliminate operator strain and prevent dust damage. Automatically optimizes cutting trajectories to process complex curves smoothly at high speeds.
◆ Broad Software & CAD/CAM Compatibility: Seamlessly integrates with AutoCAD, CorelDRAW, and Illustrator. Directly supports industry-standard formats including DXF, AI, PLT, and BMP for fast, plug-and-play production output.
Famous Brand Laser Tube
◆ RECI Laser tube is famous of good quality and the best warranty;
◆ Laser beam is more stable and longer lifetime to 10000 hours.
Blade Worktable
◆ Suitable for hard materials cutting, such as Acrylic board, Wood, MDF ect.
Honeycomb Worktable
◆ TGood for flexible material cutting, such as Fabric, Leather, Wood Veneer ect.
Auto Focus Device on Laser Head
◆ The automatic focusing device, used in conjunction with the lifting platform-Up down worktable;
◆ Accurately find the correct cutting focus when the platform height changes, saving operation time and ensuring the best cutting edge.
Up&down worktable
◆ The Z-axis move up and down automatically so that some thicker materials are not difficult to process.
◆ It is also a necessary part to work together with a rotary.
Rotary for Cylinder Engraving
◆ Rotary attachment for some cyulinders laser engraving and marking, such as glass, beer bottles and red wine bottles.
Leadshine Motor
◆ Step motor is stable and moves fast speed;
◆ High precision is suitable for laser head moving on X and Y axis.
Water Chiller for Cooling
◆ The chiller precisely controls the temperature to ensure stable laser beam for good cutting quality；
◆ Protect the lens for longer lifetime.
CCD Camera Option
◆ CCD camera is using for cut the mateirals after printed;
◆ Suitable for the printed board with marks which drawings loaded into software.
Pass Through Design of Machine Back
◆ Passing design at back of machine;
◆ It could complete continuous cutting of larger areas of material
Power Cabinet
◆ Integrated electric control cabinet, integrating laser power supply, circuit system and control system
◆ Safe and easy to maintain
Machine Parameter
No.
Item
Parameter
1
Machine Model
MCO-1390
2
Working Size
1300*900mm/900*600mm
3
Laser tube power
80w/100w/130w/180w/300w
4
Power Supply
AC220V±10% /50HZ , 110V±10%//60HZ
5
Graphic Format
BMP, PLT, DST, DXF, AI,CDR etc...
6
Compatible software
CorelDraw, PhotoShop, AutoCAD, TAJIMA
7
Driving Type
Step Morot-Option Servo
8
Transmission System
Liner Guide and Belt
9
Worktable
Blade and Honeycome Worktable
10
Laser Cutting Speed
0-4000mm/min
11
Laser Engraving Speed
0-7500mm/min
12
Red Dot
Yes
13
Min. Shaping Character
Letter 1.0 x 1.0mm
14
Machine dimension
1820 *1440 *1060 mm /1420*1140*1060mm
15
Net Weight /Gross Weight
550kg/700kg-400kg/500kg
16
Package size
1920*1540*1260mm/1520*1240*1260mm
17
Options
Up-down worktable, Rotary, WIFI, Air compressor, Servo motor, CCD camera, Auto focus device.
